Female Threaded Ball Valve

Model schedule illustration

●Series code:The series code of our company is FY

●Special requirement code: K-Antisulphur type    D-Low temperature type    EX-Pole extending type    M-Ground burying type

●Valve type code: Q-Ball valve

●Driving manner code: 3-Worm wheel and screw trensmission    6-Air driving    7-Hydrodynamic driving

                                           8-Air-hydro operated    9-Electric driving    9e-Explosion electric driving

●Connecting type code: 1-The interior whorl joining    2-The other whorl joining    4-The flange joining

                                             6-To welding joining     7-To inserting joining      8-The caliper joining

●Design feature code:1-Direct floating type 4—Floating type three direct links of Model L 5—Floating type three direct links of Model T

                                        7-Direct regular type 8-Regular type Model T three direct links 9-Regular type Model L three direct links

●Sealing formation code: Y-Hard alloy      F-Strengthen the polytetrafluoroethylene (PTFE)      N-Nylon PPL-Counterpoint polyphenyl

●Pressure grade code: The 10 times of the nominal pressure MPa, pound grade io practical number

●Body material code: C-WCB     I-WC6、ZG1Cr5Mo     V-WC9、ZG20CrMoV     P-CF8、ZG1Cr18Ni9Ti

                                          R-CF8M、ZG1Cr18Ni12Mo2Ti      S-CF3      L-CF3M      F-LCB      N-LC3

Brief Description

Female threaded ball valves are suitable for use on pipelines of medium or low pressure to turn off or switch on pipeline medium. Operation manners are in general of manual, and pneumatic or electric actuators are available. Based on design structures, the valves get divided into three pieces, two pieces and one piece.

Main size of outside & weight
